TSL.89

Air Fury High Speed Dryer

View downloads
  • Drying time 10 – 12 seconds
  • Weighs 5.32Kg
  • Noise level 77dB at 1m
  • Heating element 900W
satinClear

    Request a Quote

    Our team will respond within 48 business hours.











    Request Trade Pricing: Select Business Type

    Interested in more products? Share below. Or, for enquiries over three items, please submit requests via email to info.uk@thesplashlab.com







    Download data sheet
    TSL.89

    Downloads

    High speed drying with a high end finish

    The stylish TSL.89 high speed hand dryer can be specified in three different finishes so you can achieve a commercial washspace™ with refined aesthetics. We offer coloured hand dryers in Satin (CS), Chrome (C), White (W).

    At The Splash Lab, we design and manufacture our own commercial washroom products that work together to create a consistent design language for you. Our attention to detail, quality assurance and high level of craftsmanship results in simple design solutions that make public and commercial washroom environments better and more beautiful.

    Resources

    Datasheet

    Download

    2D CAD

    Download

    3D CAD

    Download

    All files

    Download

    Features data

    Consumption

    1600W

    Drying time

    10 - 12 seconds

    Weight

    5.32Kg (11lb 11oz)

    Stainless steel grade

    304

    Noise level

    77dB at 1m (39”)

    Air speed

    75-100m/s (246-328ft/s)

    Heating element

    900W

    Motor type

    Brush

    Air flow

    125.5 m3/h (411 ft 8 15 ”3/h)

    Sensor range

    51mm (2”) - 330mm (13”) - adjustable. Preset at 180mm (7”)

    Approvals / insulation

    Class 1 earthed, TUGGS approved, ROSH complaint, CE marked in accordance with EEC harmonised documents IPX1 rated

    Warranty

    5 years parts, 1 year labour (from date of purchase). This excludes brushes as they are a wearing part and dependant on usage

    Technical drawings

    Begin making the essential, exceptional

    Air Fury High Speed Dryer

    TSL.89

    Welcome to the support page for the TSL.89 Air Fury High Speed Dryer. On this page you’ll find video guides to repairs, common fixes, and general repairs. Plus there is a list of FAQs you may find helpful. If none of this answers your question. Please don’t hesitate to get in touch.

    FAQs

    Where can I obtain spare parts?

    Any spare parts related to your product can be found above. If you would like to see our full range of spare parts please click here.

    My dryer sounds too loud and does not run fully

    Remove the cover and check for dust or any objects that may be blocking up the dryer.

    My dryer doesn't run

    My dryer wont stop running

    My dryer runs but isn't very effective

    The air is cold

    Common fixes

    How to remove the cover

    These videos are The Splash Lab TSL recommendations and any work, especially on electrical products, must be undertaken by a qualified professional. The Splash Lab (TSL) is not responsible for any event because of following the instructions in these videos

    How to change the heater element

    These videos are The Splash Lab TSL recommendations and any work, especially on electrical products, must be undertaken by a qualified professional. The Splash Lab (TSL) is not responsible for any event because of following the instructions in these videos

    How to replace the brushes

    These videos are The Splash Lab TSL recommendations and any work, especially on electrical products, must be undertaken by a qualified professional. The Splash Lab (TSL) is not responsible for any event because of following the instructions in these videos

    How to replace the motor

    These videos are The Splash Lab TSL recommendations and any work, especially on electrical products, must be undertaken by a qualified professional. The Splash Lab (TSL) is not responsible for any event because of following the instructions in these videos

    How to replace the PCB

    These videos are The Splash Lab TSL recommendations and any work, especially on electrical products, must be undertaken by a qualified professional. The Splash Lab (TSL) is not responsible for any event because of following the instructions in these videos

    How to replace the sensor

    These videos are The Splash Lab TSL recommendations and any work, especially on electrical products, must be undertaken by a qualified professional. The Splash Lab (TSL) is not responsible for any event because of following the instructions in these videos
